The WSR-800LA Glass Installation Robot by Cowest Machinery is changing the way large glass panels are moved and installed. This smart machine makes glass handling faster, safer, and more efficient. With a lifting power of 800 kg and a working height of 4.6 meters, it is perfect for big construction and industrial projects. The robot reduces the need for manual labor, cuts costs, and improves workplace safety.
Key Features of the WSR-800LA
1. High-Efficiency Operation
The WSR-800LA has a strong 4 kW motor, allowing it to move at speeds of 0–4 km/h. This means quick positioning and less waiting time.
Flexible Movement: Its 650mm+500mm electric arm and 360° rotation help it work even in tight spaces.
Climbing Ability: It can move on slopes or uneven ground with a 12% climbing capacity.
2. Precision Installation
This robot makes sure glass panels are placed with perfect accuracy.
Adjustments: It can move ±50mm sideways and ±75mm up and down for exact positioning.
Versatile Handling: The suction cups can tilt (0°–180°) and rotate, making it easy to work with flat or curved glass.
3. Advanced Safety Systems
Safety is a top priority with the WSR-800LA.
Protections: It has alarms for vacuum loss, overload, and low battery. It also has an anti-tip device and emergency stop.
Double Suction: Dual vacuum pumps keep the glass secure even when moving.
4. Easy Remote Control
All operations are controlled with a remote, so workers can stay safe while handling glass.
Smooth Driving: The front-wheel drive helps with easy steering.
5. Long Battery Life
With two 12V-190AH batteries, the robot runs for 6–8 hours on one charge. It works with global charging standards (AC 220V/110V–240V).
Technical Specifications
Basic Details
Brand: Cowest Machinery
Model: WSR-800LA
Type: Glass Installation Robot
Max Load: 800 kg
Working Height: 4600 mm
Weight: 2190 kg
Size
Length: 3233 mm (minimum)
Width: 880 mm (minimum)
Height: 1620 mm (minimum)
Performance
Speed: 0–4 km/h
Max Glass Size: 7m × 3m (length × width)
Suction Cups: 2 × 850mm × 500mm (standard)
Optional: Curved suction cup frame for special glass shapes
Battery & Charging
Battery: 2 × 12V-190AH
Charging: AC 220V/110V–240V
Runtime: 6–8 hours
Safety Certifications
Vacuum alarm, anti-tip device, automatic brake, emergency stop, overload protection, low-battery alert.
Why Choose the WSR-800LA?
The WSR-800LA is a game-changer in glass installation. It saves time, reduces risks, and improves precision. Whether for skyscrapers, shopping malls, or factories, this robot makes glass handling easier and safer.
